ALUMINUM CONNECTORS

We are one of the leading suppliers of Aluminium Connectors

Aluminium structure connectors have many types of categories which are used for movement & fixing of aluminium profiles.

Aluminium connectors are special types of components which are typically used in forming of frame for machines, structure of room or closet, doors, windows & industrial purpose etc.

These joint parts are mainly composed of Interior joints, T-slot joints and connector link. The interior joints are mainly used for vertical connection of profiles. There are two types of angle groove connectors, such as E and L. They are used for aluminium profile right angle connections.

We provide various coating and colours according to the specification of our customers. We provide self-finish, natural finish, zinc plated, yellow finished, blue finished, black finished bolts, hot dip galvanized (HDG), geomat etc.

Types of Aluminum Connectors we are Manufacturing

img T-Nut

A socket head cap screws are machine screws with a cylindrical barrel shaped head containing a hexagonal socket. The head has a smaller diameter than most other machine screw heads, typically just 1.5 times the nominal thread diameter.

img Barrel Nut

Low head cap screws are same as socket head cap screws that feature a head containing a hexagonal socket. The socket head makes it easy to securely install the screws with hex keys or hex socket bits, while their low head makes them suitable for installation in situations where there is limited clearance.

img Anchor Joint

The Flat head screws have a large head and a cylindrical shaft with external threads. The head has a larger diameter than the threaded portion, this provides a positive mechanical stop when tightening the screw. Cap screws are tightened directly into a threaded or tapped hole, usually without a nut.

img Plate Connectors

The Button head cap screws have a low domed type head with a wider bearing surface than standard heads. Designed for light fastening applications, button head cap screws lack the strength of standard socket screws.

img Anchor Comer Cube Connector

This socket shoulder screw, often called a “stripper bolt”, is used for a wide range of punch and die operations. The shoulder screws are commonly used as fulcrums or pivots in machine designs that involve links, levers or other oscillating parts.

End Connector

It mainly is used for the porous square profile to connect caster, plays a transition role. High connection strength. Easy to install.

Free Plate Connector

Free Plate Connectors are used in aluminum profile superposition connection and can be arbitrary angle adjusted (adjustment range 0° ~ 180°).

Slide & Hook

Slide & Hook are inserted in the aluminum profile slots to slide, hook up various tools, wires and other objects.

Metal Hinge

The advantage of the metal hinges are high forte, can carry greater stress.

Hinge

Hinges are used to connect with both profiles and plates, They’re detachable.

Magnetic Lock

When the doors are closed, magnetic lock plays a fixed role and has the function of adsorption.

Inner Plate Connector

Inner Plate Connectors are applied to cross or 45° angle connection.

Outer Plate Connector

They’re applied to cross or right angle connection.

Hammerhead Nut

Hammerhead Nuts are used to install and fix the profile to the slot.

T-Bolt

Putting T-bolt into aluminum profile’s slot, it can automatic positioning lock with flange nuts.

Core Screw

Core Screw is for high strength connection of aluminum profiles.

Joint Bolt

Industrial aluminum framework generally adopts internal joint to get a connection.

Sunk Screw

Sunk Screw match with hammer-head nuts, used in hinges, door stoppers, handles, etc.

Sliding Nut

Sliding Nuts should be slipped into aluminum profile’s slot during installation.

Flange Nut

Flange nut match with T-bolts.

Spring Round Nut

Spring Round Nut belong to the preset nut which are put into profile’s slot at any assembly point.

Flexible Round Nut

Flexible Round Nut are directly put into profile’s slot at any assembly point to fix the profiles.

Specification

Industries Served

Renewable

Chimney cleaning

Automation

Water Projects

Ship building

Automobiles

Doors

Agricultural equipment & machines

Bridge construction

Hydraulic & Pneumatic

Aluminum frame construction

Parts for Ship engines / Ship Building

HVAC

Wind Turbines

Railways

Petrochemical Industries

Fastening Solutions

Aerospace

Building construction

Dams

Engine parts manufacture

Solar projects

Replacement market

Tunnel Industry

Transmission Industry

Trailer parts

Mining

Raw Materials (Metals)

Alloy Steels

Carbon Steel

Aluminum

Brass

Stainless Steel
Tin
Titanium
Nickel

Silicone Bronze

Duplex Steel

Mild Steel

Standard

ISO

IS

BS

ASME

ASTM

ANSI

DIN

Dast

Heat Treatment

Annealing

Normalizing

Hardening

Stress relieving.

Tempering.

Carburization

Heat Treated to any custom Specification

Fastener Types

Bolts & Studs

Nuts

Washer

Grades

4.6

8.8

10.9

12.9

B7

L7

B8M

SS 304

SS 316

SS 316L

SS 316 S31 etc.

4

8

10

12

2H

2HM

8A

8M

8MA etc.

MS

Carbon Steel

HV 100

HV 200

HV 300

A4

SS etc.

Thread

Metric

UNC

UNF

Diameter

M12-M100

½’ to 4”

Finish

Brass

Bronze

Chrome

Nickel-Plated

Zinc Electroplated

Electro galvanizing

Hot Dip Galvanizing

Ceramic Coating

Xylan or Teflon Coating

PTFE Coating

Geomat etc.
